Mass Batch Production Fixed Vacuum Homogenzing Emulsifier
Cosmetic Vacuum Homogenizing Emulsifier
- Overview
- Quick Detail
- Description
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
| Place of Origin: | Jiangsu China |
| Brand Name: | SINA EKATO |
| Model Number: | SME-B |
| Certification: | ISO9001, CE |
| Minimum Order Quantity: | 1 SET |
| Delivery Time: | 50days |
| Supply Ability: | 500-5000L |
Quick Detail
1. Alternative Names: Fixed Type Emulsifier, Stationary Homogenizer,Bottom-Homogenization Emulsifier
2. Main Applications
Cosmetics: Foundation, Cold Cream, Sun screen.
Pharmacy: Ointment, Suppository.
Food: Mayonnaise, Salad Dressing, Emulsified Vinaigrette.
Core Specifications and Parameters
| Parameter Category | Core Parameter Items | Common Specification Range |
| Emulsifying Pot Parameters | Effective Volume | 500L - 5000L (mass production models) |
| Material | Inner Pot: 316L Stainless Steel (food/pharmaceutical grade); Outer Pot: 304 Stainless Steel | |
| Jacket Design | Equipped with heating/cooling jacket, compatible with steam or electric heating | |
| Homogenizing & Emulsifying System | Bottom Homogenizer Speed | 0 - 3000r/min (variable frequency speed regulation) |
| Stirring Paddle Configuration | Bidirectional helical-ribbon agitation with wall scraper (Clockwise and counterclockwise agitation) rotating speed: 0 - 45r/min | |
| Vacuum System | Vacuum Degree | ≤ -0.095MPa (adjustable to meet defoaming requirements) |
| Heating & Cooling System | Heating Temperature Range | Room Temperature - 120℃ (temperature control accuracy: ±1℃) |
| Cooling Method | Rapid cooling via circulating cooling water in the jacket | |
| Control System | Operation Interface | PLC + touch screen control, with production formula storage function |
| Safety Protection | Vacuum overload protection, over-temperature alarm, motor overload protection |
Description
The Fixed Vacuum Homogenizing Emulsifier is a high-performance homogenization system designed for the stable, large-scale production of high-viscosity emulsions. Unlike lifting models, its fixed-cover design ensures superior air tightness and structural integrity, making it the ideal choice for vacuum deaeration.
-
Key Features:
-
High-Shear Homogenization: Precision rotor-stator system for ultra-fine particle distribution.
-
Vacuum Deaeration: Processes materials in a full vacuum to eliminate bubbles and prevent oxidation.
-
Efficient Agitation: Bidirectional Ribbon-Frame agitator with PTFE wall scrapers for 100% coverage.
-
GMP Standard: Full SUS316L stainless steel construction with a mirror-polished finish.
-
-
Applications: Cosmetics (Face Cream/Lotion), Pharmaceuticals (Ointment/Gel), Food (Mayonnaise/Sauce), and Fine Chemicals.
Applications
| Daily cosmetic | |||
| hair conditioner | facial mask | moisturizing lotion | suncream |
| skin care | face lotion | body lotion | sunscreen cream |
| cream | hair cream | cosmetic paste | BB Cream |
| lotion | face wash liquid | eye serum | hair gel |
| hair dye | lip balm | serum | lip gloss |
| emulsion | lipstick | Highly viscous product | shampoo |
| cosmetic toner | hand cream | shaving cream | moisturizing cream |
| Pharmaceutical | |||
| Topical Ointment | Topical Cream | Topical Patches | Topical gel |
| Fulibuprofen Gel Patches | Adapalene Gel | Neomycin Ointment | Mupirocin Ointment |
| Food | |||
| cheese | milk butter | wasabi | mayonnaise |
| ketchup | mustard | margarine | Salad dressing |
Specifications
|
Model |
Capacity |
Homogenizer Motor |
Stir Motor |
Dimension |
Total power（KW） |
Limit vacuum（Mpa） |
|||||
|
KW |
r/min |
KW |
r/min |
Length（mm） |
Width（mm） |
Height（mm） |
Steam heating |
Electric heating |
|||
|
SME-B-100 |
100L |
2.8-4 |
0-3000 |
1.5 |
0-63 |
2750 |
2700 |
2250 |
13 |
32 |
-0.09 |
|
SME-B-200 |
200L |
6.5-8 |
0-3000 |
2.2 |
0-63 |
3100 |
3000 |
2500 |
15 |
45 |
-0.09 |
|
SME-B-300 |
300L |
6.5-8 |
0-3000 |
2.2 |
0-63 |
3500 |
3350 |
2650 |
18 |
49 |
-0.085 |
|
SME-B-500 |
500L |
6.5-8 |
0-3000 |
4 |
0-63 |
3850 |
3600 |
2750 |
22 |
61 |
-0.08 |
|
SME-B-1000 |
1000L |
9-11 |
0-3000 |
5.5 |
0-53 |
4200 |
3850 |
3300 |
28 |
88 |
-0.08 |
|
SME-B-2000 |
2000L |
11-14 |
0-3000 |
5.5 |
0-53 |
4500 |
4050 |
3800 |
34 |
- |
-0.08 |
|
SME-B-3000 |
3000L |
15-18 |
0-3000 |
7.5 |
0-53 |
4800 |
4300 |
4100 |
40 |
- |
-0.08 |
Competitive Advantage
· Siemens motor and frequency converter for speed adjustment, which can meet production of different technology requirement.
· The vacuum defoaming can make the materials meet the requirement of being aseptic. The vacuum material sucking adopted can avoid dust especially for the powder products.
· Mechanical sealing, good sealing effect and long working life.
· The tank body and the pipes adopt mirror polishing, which fully conforms to GMP standards.
· Material contact parts all use SUS316L stainless steel.
· The heating method mainly include electric or steam heating accodring to customer's choice.
