Steam Jacketed Tank Stainless Steel Mixer Alcohol Gel Shampoo Reactor Shower Gel Agitator Mixer Tank
- Overview
- Quick Detail
- Description
- Applications
- Specifications
- Competitive Advantage
- Recommended Products
Overview
| Place of Origin: | Jiangsu China |
| Brand Name: | SINA EKATO |
| Model Number: | PME |
| Certification: | ISO9001, CE |
| Minimum Order Quantity: | 1 SET |
| Delivery Time: | / |
| Supply Ability: | 200L-10000L |
Quick Detail
1. Alternative Names: Liquid Soap Mixer, Shampoo Making Machine, Detergent Mixing Tank, Liquid Blending Vessel, Agitator Tank2.
2. Main Applications
Personal Care: Manufacture of shampoo, body wash, hand soap, conditioner, etc
Home Care: Production of dishwashing liquid, laundry detergent, glass cleaner, and other liquid cleaning agents.
Chemicals: Mixing, dissolving, blending, and heating/cooling treatment of various low-viscosity liquids.
Core Specifications and Parameters
| Working Capacity | 100L - 5,000L (Supports customization for ultra-large capacities) |
| Stirring Speed | 0 – 63 RPM (Variable speed drive with PTFE wall scraper agitator) |
| Homogenizing | Optional bottom homogenizer or in-line homogenizer (0–3600 RPM) |
| Material Quality | SUS316L (material contact layer), SUS304 (outer layer), mirror polish |
| Heating Method | Steam heating or Electric heating |
| Discharging | Direct discharge via pot bottom valve or material pump transfer |
| Structure | Single-layer / Double-layer with insulation / Triple-layer with heating |
Description
1. The triple mixing adopts the imported frequency inverter for speed adjustment, which can meet different technological demands.
2. The homogenizing structure is made through German technology. The machine adopts the improted double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 3500rpm and the high shearing fineness can reach 0.2-5um.
3. The vacuum defoaming can make the materials meet the requirement of being aseptic . The vacuum materials vacuum sucking can avoid dust.
4. The main boiler lid can adopt lifting system, it is easy to clean and the cleaning effect is more obvious, the main boiler can adopt tilting discharge.
5. The boiler body is welded with 3 layer imported SS plate, tank body and pipes adopts mirror polish which meet the GMP standard.
6. According to process requirement, the tank body can heating and cooling the electric heating.
7. To ensure the stability of whole machine, the machine adopt the imported electric appliances which can meet the international standards.
Applications
· Personal Care: Shampoo, Liquid Soap, Shower Gel, Hand Sanitizer, Hair Conditioner.
· Home Care: Dishwashing Liquid, Laundry Detergent, Fabric Softener, Glass Cleaner.
· Chemical Industry: Liquid Fertilizers, Lubricants, Paints, and Specialty Blending.
Specifications
| Model | Capacity | Mixing power(kw) | Mixing speed(r/min) | Homogenizing power(kw) | Homogenizingspeed(r/min) | Heating method |
| PME-200 | 200L | 0.75 | 0-65 | 2.2-4 | 3000 | Steam HeatingOrElectric Heating |
| PME-300 | 300L | 0.75 | 0-65 | 2.2-4 | 3000 | |
| PME-500 | 500L | 2.2 | 0-65 | 5.5-7.5 | 3000 | |
| PME-1000 | 1000L | 4 | 0-65 | 7.5-11 | 3000 | |
| PME-2000 | 2000L | 5.5 | 0-53 | 11-15 | 3000 | |
| PME-3000 | 3000L | 7.5 | 0-53 | 18 | 3000 | |
| PME-5000 | 5000L | 11 | 0-42 | 22 | 3000 | |
| PME-10000 | 10000L | 15 | 0-42 | 30 | 3000 | |
| Note:In case of inconformity of the data in the table due to technical improvement or customization,the real object shall prevail. | ||||||
Competitive Advantage
· Advanced Scraper Mixing System: Equipped with a frequency-controlled (VFD) frame-type agitator, the mixer ensures thorough blending of all ingredients. The unique PTFE (Teflon) scrapers maintain constant contact with the tank wall, preventing material adhesion (charring) and significantly enhancing heat transfer efficiency.
· High-Shear Dispersing & Homogenizing: To ensure a crystal-clear and smooth final product, the unit can be configured with a bottom-entry or top-entry high-speed disperser. This system rapidly breaks down surfactants (like AES/LAS) and powders, reducing production time and ensuring a consistent, lump-free texture.
· Pharmaceutical-Grade SUS316L Construction: Recognizing the corrosive nature of many cleaning agents, all contact parts are crafted from premium SUS316L stainless steel. Both internal and external surfaces undergo high-precision mirror polishing (Ra ≤ 0.4μm), complying with strict GMP standards and making the cleaning process effortless.
· Triple-Layer Jacketed Design: The vessel features a triple-layer structure designed for electric or steam heating. The high-precision temperature control system (integrated with PT100 sensors) ensures that the formula reacts at the optimal temperature. The middle insulation layer prevents heat loss, saving energy while ensuring operator safety.
· Customizable & Modular Configurations: Whether you require a simple single-layer tank for blending or a fully automated system with a Siemens PLC touch screen, our mixers are fully customizable. Options include various impeller types, load cell weighing systems, and integrated discharge pumps to suit your specific factory layout.
