Perfume Vacuum Filling Packing Machine Fragrance Oil Filling Packing Machine

Overview

Place of Origin:	Jiangsu China
Brand Name:	SINA EKATO
Model Number:	XS
Certification:	ISO9001, CE
Minimum Order Quantity:	1 SET
Packaging Details:	Standard export wooden case
Delivery Time:	30-45 working days
Payment Terms:	T/T, L/C

Quick Detail

The semi-automatic 4-head perfume filling machine is a professional precision filling equipment customized for the perfume, cosmetic and daily chemical industry, engineered for quantitative filling of perfume, essential oil, fragrance water and other low-viscosity, volatile liquid products. Adopting 4 independent filling heads with high-precision flow control, it balances manual flexible operation and automatic quantitative filling, featuring fast filling speed, high accuracy and no liquid leakage/splash. It is the ideal core equipment for small and medium-sized perfume production lines, trial production workshops and customized batch production, perfectly matching the filling demand of perfume glass spray bottles, roll-on bottles and small capacity cosmetic containers (5ml-100ml).

Description

The Macine Working Principle

1. Manual Positioning: Place the empty perfume bottles on the positioning tray manually, adjust the bottle support height to fit different bottle shapes/sizes, and push the tray to the filling station for automatic positioning.
2. Quantitative Filling: After starting the equipment, the 4 filling heads descend synchronously, and the high-precision volumetric pump delivers the perfume liquid to each bottle at a constant speed according to the preset filling volume; the built-in anti-foam flow control valve slows down the filling speed at the later stage to avoid foam generation caused by rapid liquid impact.
3. Automatic Reset & Discharging: After the filling is completed, the filling heads rise automatically and the anti-drip nozzles seal instantly to prevent liquid leakage and volatilization; pull out the positioning tray manually to take out the filled bottles, completing one filling cycle.
4. The equipment supports real-time adjustment of filling parameters, and the 4 filling heads can also work independently for single/batch filling of different specifications, meeting diversified production needs.

Key Structural & Design Features

1. 4 Independent High-Precision Filling Heads
   Equipped with imported volumetric ceramic pumps, filling accuracy ≤±0.5%, 4 heads fill synchronously to double the production efficiency compared with single/double head models; each head has an independent flow regulating valve for separate volume calibration, adapting to filling of different capacities (5ml-100ml) without replacing parts.
2. Anti-Volatility & Anti-Drip Optimization
   Special PTFE anti-drip nozzles with automatic sealing function, effectively prevent perfume volatilization and liquid splash during filling; the liquid contact parts are fully closed to reduce the contact between perfume and air, lock the aromatic components and avoid fragrance loss.
3. Pneumatic-Electric Integrated Safe Control
   Adopt brand pneumatic components and microcomputer control system, low noise, stable operation and simple operation; equipped with emergency stop button, anti-pinch protection and pressure overload alarm, ensuring safe operation of operators; the control panel is with clear digital display, realizing one-key setting of filling volume, speed and delay time.
4. Flexible Adaptation to Various Containers
   Height-adjustable bottle support and positioning baffle, compatible with various perfume bottle types (round, square, irregular shape) and container materials (glass, PET); the positioning tray is detachable for quick cleaning and replacement, suitable for multi-specification small batch production.
5. Food-Grade Sanitary Material for Liquid Contact Parts
   All parts in contact with perfume liquid are made of 316L stainless steel (meets GMP cosmetic production standards), with mirror polishing inside, no dead angle, corrosion resistance and solvent resistance; easy to disassemble and clean, avoiding cross-contamination between different formulas and meeting the hygienic requirements of perfume production.
6. Compact & Durable Structure
   Integral heavy-duty stainless steel frame, stable and non-shaking during operation, no need for fixed installation; compact overall size, saving workshop space, easy to move and integrate into the semi-automatic perfume production line (matching capping, labeling machine).

Applications

• Quantitative filling of various perfumes (eau de parfum, eau de toilette, cologne) in 5ml-100ml glass/plastic bottles.
• Filling of low-viscosity volatile liquids in daily chemical/cosmetic industry (essential oil, fragrance water, facial mist, roll-on perfume).
• Small and medium batch production, formula trial production and customized processing in perfume factories and cosmetic processing plants.
• Filling of small capacity high-value liquids in daily chemical laboratories and small-scale production workshops.

Specifications

Competitive Advantage

• Dual Efficiency & Precision: 4-head synchronous filling, production capacity up to 800-1200 bottles/hour; volumetric quantitative technology, filling accuracy ≤±0.5%, ensuring consistent liquid level of finished perfume bottles.
• Perfume Formula Protection: Closed liquid path + anti-drip anti-volatility nozzles, minimize perfume volatilization and fragrance loss, protect the purity of precious essence formulas.
• Flexible & Easy Operation: No professional training required, one-key start, manual positioning is simple and flexible; independent adjustment of filling heads, suitable for multi-specification, small-batch customized production.
• GMP Compliance & Sanitary: 316L stainless steel liquid contact parts, mirror polishing, detachable design, easy to clean and sterilize, in line with cosmetic and daily chemical industry GMP production specifications.
• Stable & Low-Cost Operation: Pneumatic-electric integrated design, few wearing parts, low failure rate and easy maintenance; no need for large air source, low energy consumption, reducing production and maintenance costs.
• Anti-Foam & Leakage-Free: Special flow control and anti-foam structure, avoid foam generation and liquid splash, reduce raw material waste and workshop pollution.
